| Marca | TP-Link |
| Modelo | TL-SG1005LP |
| Características de Hardware | - Interfaz: 8 × 100/1000/2500 Mbps RJ45 PoE+ Ports 2 × 10G SFP+ Slots - Cantidad de ventiladores: Fanless - Bloqueo de Seguridad Física - Fuente de Alimentación: Adaptador de Corriente 53.5VDC/3.37A - Puertos PoE (RJ45) Estándar: compatible con 802.3at/af Puertos PoE+: 8 puertos Presupuesto de energía PoE: 160 W - Montaje: Sobremesa/Pared - Consumo de Potencia Máximo: 180,1 W (110V/60Hz) (con 160 W PD conectado) - Disipación máxima de calor: 614,58 BTU/hr (110 V/60 Hz) (con 160 W PD conectado) - Dimensiones: 226 × 131 × 35 milímetros |
| Rendimiento | - Capacidad de Conmutación: 80 Gbps - Tasa de Reenvío de Paquetes: 59.52 Mpps - Tabla de Direcciones MAC: 16 K - Memoria del Buffer de Paquete: 12 Mbit - Jumbo Frame: 9 KB |
| Características de Software | Calidad de Servicio - 802.1p CoS/DSCP priority - 8 priority queues - Priority Schedule Mode SP (Strict Priority) WRR (Weighted Round Robin) - Queue Weight Config - Bandwidth Control Port/Flow based Rating Limit - Smoother Performance - Storm Control Multiple Control Modes(kbps/ratio) Broadcast/Multicast/Unknown-Unicast Control Características L2 y L2+ - 32 IP Interfaces: Support IPv4/IPv6 Interface - Static Routing: 32 IPv4/IPv6 Static Routes - DHCP Server - DHCP Relay DHCP Interface Relay DHCP VLAN Relay - DHCP L2 Relay - Static ARP - Proxy ARP - Gratuitous ARP - Link Aggregation - Spanning Tree Protocol - Loopback Detection - 802.3x Flow Control - Mirroring - Device Link Detect Protocol (DLDP) - 802.1ab LLDP/ LLDP-MED Multicast L2 - 511 IPv4, IPv6 shared multicast groups - IGMP Snooping - Multicast VLAN Registration (MVR) - Multicast Filtering - Limited IP Multicast (256 profiles and 16 entries per profile) Características Avanzadas - Automatic Device Discovery - Batch Configuration - Batch Firmware Upgrading - Intelligent Network Monitoring - Abnormal Event Warnings - Unified Configuration - Reboot Schedule VLAN - VLAN Group Max 4K VLAN Groups - 802.1Q Tagged VLAN - MAC VLAN: 12 Entries - Protocol VLAN - GVRP - Voice VLAN Lista de Control de Acceso - Support up to 230 entries - Time-based ACL - MAC ACL - IP ACL - IPv6 ACL - Combined ACL - Rule Operation: Permit/Deny - Policy Action Mirroring Redirect Rate Limit QoS Remark - ACL Rules Binding Port Binding VLAN Binding Seguridad - IP-MAC-Port Binding - AAA - 802.1X Port based authentication MAC (Host) based authentication Authentication Method includes PAP/EAP-MD5 MAB Guest VLAN Support Radius authentication and accountability - IP/IPv6-MAC Binding 512 Binding Entries DHCP Snooping DHCPv6 Snooping ARP Inspection ND Detection ND Snooping - IP Source Guard 253 Entries Source IP+Source MAC - IPv6 Source Guard 183 Entries Source IPv6 Address+Source MAC - DoS Defend - DHCP Filter - Static/Dynamic/Permanent Port Security Up to 64 MAC addresses per port - Broadcast/Multicast/Unicast Storm Control - Port Isolation - Secure web management through HTTPS with SSLv3/TLS 1.2 - Secure Command Line Interface (CLI) management with SSHv1/SSHv2 - IP/Port/MAC based access control IPv6 - IPv6 Static Routing and ACL - IPv6 Dual IPv4/IPv6 - IPv6 Interface - Multicast Listener Discovery (MLD) Snooping - IPv6 neighbor discovery (ND) - Path maximum transmission unit (MTU) discovery - Internet Control Message Protocol (ICMP) version 6 - TCPv6/UDPv6 - IPv6 applications DHCPv6 Client Ping6 Tracert6 Telnet(v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP MIBs - MIB II (RFC1213) - Interface MIB (RFC2233) - Ethernet Interface MIB (RFC1643) - Bridge MIB (RFC1493) - P/Q-Bridge MIB (RFC2674) - RMON MIB (RFC2819) - RMON2 MIB (RFC2021) - Radius Accounting Client MIB (RFC2620) - Radius Authentication Client MIB (RFC2618) - Remote Ping, Traceroute MIB (RFC2925) - Support TP-Link private MIB |
| Gestión | - Aplicación Omada: Requerir el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller - Gestión Centralizada Controlador Omada Basado en la Nube Controlador de hardware Omada Controlador de software Omada - Acceso a la nube Sí. Requerir el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller - Aprovisionamiento sin contacto Sí. Requiere el uso del controlador basado en la nube Omada. - Funciones de gestión GUI basada en web Interfaz de línea de comando (CLI) a través de telnet SNMPv1/v2c/v3 Captura/información SNMP RMON (1,2,3,9 grupos) Plantilla SDM Cliente DHCP/BOOTP Imagen dual, configuración dual Monitoreo de CPU Diagnóstico de cables AEE SNTP Registro del sistema |
| Otros | - Certificaciones: CE, FCC, RoHS - Requisitos del sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux Contenido - SG2210XHP-M2 Switch - Power Adapter - Quick Installation Guide - Rubber Feet |
| Fecha de revisión | 07-11-2024 por RTY |
