| Marca | TP-Link |
| Modelo | SG3428XF |
| Interfaz | - 20 × ranuras SFP Gigabit - 4 x puertos Gigabit combinados SFP/RJ45 - 4 x ranuras SFP+ 10G - 1 × puerto de consola RJ45 - 1 × puerto de consola micro-USB |
| Características de Software |
- Descubrimiento automático de dispositivos - Configuración por lotes - Actualización del firmware por lotes - Monitoreo de red inteligente - Advertencias de eventos anormales - Configuración unificada - Programación de reinicio Calidad de Servicio - 8 priority queues - 802.1p CoS/DSCP priority - Queue scheduling: SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR - Bandwidth Control: Port/Flow-based Rating Limiting - Smoother Performance - Action for Flows: QoS remark (802.1P Remark, DSCP Remark) Características L2 y L2+ - 128 IP Interfaces: Support IPv4/IPv6 Interface - Static Routing: 48 IPv4/IPv6 Static Routes - Static ARP: 128 static entries - 512 ARP Entries - Proxy ARP - Gratuitous ARP - DHCP Server - DHCP Relay: DHCP Interface Relay, DHCP VLAN Relay - DHCP L2 Relay - Link Aggregation - Spanning Tree Protocol - Loopback Detection - 802.3x Flow Control - Mirroring Multicast L2 - Supports 1000 (IPv4, IPv6) IGMP groups - IGMP Snooping - IGMP Authentication - Multicast VLAN Registration (MVR) - MLD Snooping - Multicast Filtering: 256 profiles and 16 entries per profile Funciones del ISP - L2PT (Layer 2 Protocol Tunneling) - Device Link Detect Protocol (DLDP) - PPPoE ID Insertion - ERPS - 802.3ah Ethernet Link OAM - DDM - sFlow VLAN - VLAN Group: Max 4K VLAN Groups - 802.1q Tagged VLAN - MAC VLAN: 30 Entries - Protocol VLAN: Protocol Template 16, Protocol VLAN 16 - Private VLAN - GVRP - VLAN VPN: VLAN Mapping, VLAN Replace - Voice VLAN Lista de Control de Acceso - Time-based ACL - MAC ACL: Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type - IP ACL: Source IP, Destination IP, Fragment, IP Protocol, TCP Flag, TCP/UDP Port, DSCP/IP TOS - Combined ACL - Packet Content ACL - IPv6 ACL - Policy: Mirroring, Redirect, Rate Limit, QoS Remark - ACL applies to Port/VLAN Seguridad - IP-MAC-Port Binding 512 Entries DHCP Snooping ARP Inspection IPv4 Source Guard - IPv6-MAC-Port Binding 512 Entries DHCPv6 Snooping ND Detection ND Snooping IPv6 Source Guard - DoS Defend - Static/Dynamic Port Security: Up to 64 MAC addresses per port - Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode - 802.1X Port base authentication MAC-based authentication VLAN Assignment MAB Guest VLAN Radius authentication and accountability support - AAA (including TACACS+) - Port Isolation - Secure web management through HTTPS with SSLv3/TLS 1.2 - Secure Command Line Interface (CLI) management with SSHv1/SSHv2 - IP/Port/MAC-based access control IPv6 - IPv6 Dual IPv4/IPv6 - Multicast Listener Discovery (MLD) Snooping - IPv6 ACL - IPv6 Interface - Static IPv6 Routing - IPv6 neighbor discovery (ND) - Path maximum transmission unit (MTU) discovery - Internet Control Message Protocol (ICMP) version 6 - TCPv6/UDPv6 - IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP MIBs - MIB II (RFC1213) - Interface MIB (RFC2233) - Ethernet Interface MIB (RFC1643) - Bridge MIB (RFC1493) - P/Q-Bridge MIB (RFC2674) - RMON MIB (RFC2819) - RMON2 MIB (RFC2021) - Radius Accounting Client MIB (RFC2620) - Radius Authentication Client MIB (RFC2618) - Remote Ping, Traceroute MIB (RFC2925) - Support TP-Link private MIB |
| Características | - Cantidad de Ventiladores: 1 x ventilador - Bloqueo de Seguridad Físico - Fuente de Alimentación Dual Redundant Power Supplies 100-240 V AC~50/60 Hz - Montaje: Rack Mountable - Consumo de Potencia Máximo: 35.7 W (110 V/60 Hz) - Disipación máxima de calor: 121.81 BTU/hr (110 V/60 Hz) - Capacidad de Conmutación: 128 Gbps - Tasa de Reenvío de Paquetes: 95.23 Mpps - Tabla de Direcciones MAC: 16 K - Memoria del Buffer de Paquete: 12 Mbit - Jumbo Frame: 9 KB - Requisitos del sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux. - Omada Ap: Requiere el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller - Gestión Centralizada: Controlador basado en la nube Omada Controlador de hardware Omada Controlador de software Omada - Acceso a la nube: Requiriendo el uso de Omada Hardware Controller, Omada Cloud-Based Controller o Omada Software Controller - Aprovisionamiento sin contacto: Requiere el uso de Omada Cloud-Based Controller Funciones de gestión - Web-based GUI - Command Line Interface (CLI) through the console port, telnet - SNMP v1/v2c/v3: Trap/Inform, RMON (1,2,3,9 groups) - SDM Template - DHCP/BOOTP Client - 802.1ab LLDP/LLDP-MED - DHCP AutoInstall - Dual Image, Dual Configuration - CPU Monitoring - Cable Diagnostics - EEE - Password Recovery - SNTP - System Log Certificaciones - CE, FCC, RoHS Dimensiones - 440 × 220 × 44 mm Contenido - SG3428XF Switch - Power Cord - Quick Installation Guide - Rackmount Kit - Rubber Feet |
| Fecha de revisión | 19-08-2024 por RTY |
